A1200 IPU-3M 18,000GPH Controllable DC Pump – Abyzz

(This product is dropshipped from Abyzz)

Abyzz A1200 IPU Pumps are perfect for:

Saltwater marine and reef aquariums
Freshwater aquariums
Pond filter systems
Creeks
Water features
Commercial applications

Abyzz pumps are world-renowned for their exceptional build quality and industry-leading 10-year manufacturer warranty. Serious aquarium hobbyists, maintenance professionals, and public aquariums trust Abyzz pumps over any other brand. Abyzz pumps are quiet, powerful, and built to last a lifetime. The company has earned a reputation for outstanding customer support and offers unparalleled warranty coverage to give you peace of mind that you’ve made the right decision when installing an Abyzz pump.

The Abyzz A1200 IPU is very versatile and can be used underwater (internal/submersible) or outside of water (externally). The pump is not self-priming, though, so it needs to be mounted under the water level.

Check out the specs of the Abyzz A1200 IPU Pump:

Maximum flow rate: 18,000 GPH (BOOSTMODE®)
Rated flow rate: 12,700 GPH
Pump ambient temperature: 34-122°F
Driver ambient temperature: 32-86°F (without additional cooling)
Maximum discharge speed: 19.7 feet per second
Delivery height: 41 feet
Power consumption: 4-1200W
Operating voltage: 100-240V~
Operating frequency: 50-60Hz
Maximum operating pressure: 17.4 PSI
Maximum immersion depth: 6.5 feet
Pump cable length: 3M (10 feet)
Inlet/outlet connections (metric) : 90/75mm (suitable for PVC/AVB adhesive fittings, imperial adapters available)

The Abyzz A1200 IPU pump has a titanium impeller, a programmable driver, and a sine-wave controlled, three-phase synchronous pump. The efficiency of the motor is more than 90%, which, along with the fact that you can adjust the speed to meet your performance requirements, makes it an energy-saving solution.

The integrated bearing flushing provides optimum protection against calcination. In conjunction with the silicon carbide bearings and special hard metal shaft, you are certain to have a very low-maintenance operation.

All the materials used are designed to have a long lifetime and meet the highest requirements and quality standards. The Abyzz A1200 IPU was developed and manufactured in Germany by venotec.

The A1200 IPU also has a 0-10v port for external control from aquarium controllers like the CoralVue HYDROS Control 4, CoralVue HYDROS WaveEngine, Neptune Systems Apex, and GHL ProfiLux.

Here are some of our favorite features of the Abyzz A1200 IPU Pump:

Variable speed range (0.0 – 100.0%)
Precise speed adjustment in steps of 0.1%
Integrated programming to generate waves, bursts, and random flow patterns with additional BOOSTMODE to override actual programming (MCFS – Menu Controlled Flow Sequencer)
Comprehensive safety functions, such as dry run warning, temperature alert, overcurrent protection, speed zero alert)
Soft startup
Auxiliary port for future modules and interfacing (software upgrade might be required)
Available with a 3m or 10m Driver/Controller Connecting Cable
Lockable cables and plug connections
Remarkably low-noise operation
Removable motor stand and rotatable volute
Multicolor background LCD display
Splashproof driver (IP65)
High-quality IP65 motor cable connector
Wide range input with active power factor correction
Optimized heat sink design
Can be used internally or externally
10-year warranty

Medium Pressure (MP) Version

The MP (medium pressure) version of this pump is suitable for low to medium head pressure systems and is designed to reach maximum efficiency between 1 (3.28 feet) and 10 meters (32.8 feet) of head pressure.
